Liposuction Pumps
PAL® Infiltration Pump
Integrates with the PAL System to activate the peristaltic pump from the PAL-750 Handpiece. Custom electronic controls ensure consistent flow at low speeds and a cooling fan prevents overheating of the motor from heavy use. PAL Infiltration Tubing eliminates obstructions with a large-bore design and smooth connections.LipoTower®
A UL-listed surgical cart featuring quiet, yet powerful, dual pumps for aspiration and a peristaltic infiltration pump with an adjustable flow rate.The on|off function of the vacuum can be controlled by a foot pedal or (when paired with a PAL System) controlled by the throttle switch of the PAL handpiece.
PAL Infiltration System
INF-PUMP, INF-CBL-5020, INF-FOOT-1, PAL-INF-1600, PAL-INF-XXXXX, PAL-INF-RXXXXX
Features
- Custom electronic controls to ensure consistent flow at low speeds
- An internal cooling fan to prevent motor overheating
- Three rollers for smooth flow
- 60-watt universal input power supply compatible with USA and international AC power sources
- Interlock circuits that stop movement when the pump head is opened
- A pump head that accepts all types of infiltration tubing with a 2.4mm wall thickness
Reference document(s): IM-INF-PUMP Rev B, LIT-INF-PUMP Rev B
Specifications
- Maximum Flow Rate: 1,150 ml/min (with PAL® Infiltration Tubing)
- Output Torque: 175 oz-in
- AC Frequency: 50 Hz or 60 Hz
- AC Voltage: 100-240V~
- Input Power Rating: 100VA
- Weight: 4.23 Kg (9.32lbs)
- Dimensions: 29 x 26 x 13cm (11.2 x 10.1 x 5.1in)
- Protection Against Electric Shock: Class I Grounded Equipment with Type BF Applied Part
- Liquid Ingress Rating: IPX1
« HIT PLAY
Watch Dr. Luis Macias explain how his PAL Infiltration Pump – the ONLY pump to seamlessly integrate with his PAL handpiece – increases efficiency during simultaneous separation and tumescent procedures.
LipoTower
Features
- Single-hand adjustable I.V. pole
- Easy-access biofilter
- Infiltration module with speed adjustment
- PAL integration provides on|off control of the vacuum pumps from the PAL-750 handpiece
- Smooth-rolling, durable casters with locks
Reference document(s): LIT-ASP-1021 Rev C
Specifications
- Vacuum Pump: Dual 1/4-Horsepower, Rotary Vane
- Vacuum Flow Rate: 3.0 SCFM (0.08 m3/min)
- Vacuum Pressure: 0–29 in/Hg (0–736 mm/Hg) at Sea Level
- Weight: 185 lbs (84 kg)
- Height: 4′ (1.2 m) Pole Down; 7′ (2.1 m) Pole Extended
- Footprint: 2′ x 2′ (0.6 m x 0.6 m)
- Electrical: 120 V, 60 Hz (UL-Listed)
Request a Quote
Our innovative solutions are tailored to elevate your practice, providing precision, reliability, and unmatched quality. Whether you’re a healthcare professional or a facility manager, our comprehensive range of advanced medical devices is designed to meet your unique needs. Take the first step towards transformative solutions today.
Resources
PAL® Infiltration System Brochure
The PAL® Infiltration Pump integrates with the PAL® System to activate the peristaltic pump from the PAL handpiece.
Learn More LipoTower Brochure
The LipoTower is a UL-listed surgical cart featuring quiet, powerful dual pumps for aspiration and a peristaltic infiltration pump with an adjustable flow rate.
Learn MoreRelated Products
PAL System
PAL’s smooth reciprocating cannulas glide through tissue, reducing the amount of physical effort required during liposuction, thus reducing O.R. time.5
Featuring the ergonomic PAL-750 handpiece.
Learn More
Fat Processing
The LipoFilter uses a gravity-decanting system to separate fluids from adipose tissue.
Learn MoreImages
